Horizontal scraper centrifuge

With excellent product quality and excellent technical services have been praised by users.

MORE +

LLW horizontal screw discharge

China centrifuge professional manufacturers set product design, manufacturing, sales, maintenance and spare parts services

MORE +

scroll down

Product display

Integrity first, win-win cooperation, do our best to create the greatest value for customers.

LWL horizontal filter sedimentation centrifuge

The LLW centrifuge is a kind of horizontal screw discharge, continuous operation of the filtration equipment. The drum and the spiral rotate at a certain differential speed in the same direction and high speed, the material is continuously introduced into the inner cylinder of the conveying screw by the feed pipe, and enters the drum after acceleration, under the action of the centrifugal force field, the liquid phase passes through the filter medium and discharges the machine, and the solid phase is trapped in the drum to form filter residue, and the filter residue moves continuously to the large end of the drum to discharge the drum under the joint action of the cone component of the centrifugal force and the conveying spiral, and discharges the drum through the discharge chute.
Application fields: chemical industry, salt production, alkali production, environmental protection and other industries.
Advantages and characteristics: compact structure, small size, continuous operation, stable operation, strong adaptability, large processing capacity, low moisture content of filter cake and so on.

LW (LWS) screw pusher centrifuge

The LW centrifuge is a kind of horizontal screw discharge, continuous operation of the filtration equipment. The drum and the spiral rotate at a certain differential speed in the same direction and high speed, the material is continuously introduced into the inner cylinder of the conveying screw by the feed pipe, and enters the drum after acceleration, under the action of the centrifugal force field, the liquid phase passes through the filter medium and discharges the machine, and the solid phase is trapped in the drum to form filter residue, and the filter residue moves continuously to the large end of the drum to discharge the drum under the joint action of the cone component of the centrifugal force and the conveying spiral, and discharges the drum through the discharge chute.
Application fields: chemical industry, salt production, alkali production, environmental protection and other industries.
Advantages and characteristics: compact structure, small size, continuous operation, stable operation, strong adaptability, large processing capacity, low moisture content of filter cake and so on.

LLW type horizontal screw discharge

The LLW centrifuge is a kind of horizontal screw discharge, continuous operation of the filtration equipment. The drum and the spiral rotate at a certain differential speed in the same direction and high speed, the material is continuously introduced into the inner cylinder of the conveying screw by the feed pipe, and enters the drum after acceleration, under the action of the centrifugal force field, the liquid phase passes through the filter medium and discharges the machine, and the solid phase is trapped in the drum to form filter residue, and the filter residue moves continuously to the large end of the drum to discharge the drum under the joint action of the cone component of the centrifugal force and the conveying spiral, and discharges the drum through the discharge chute. The machine can continuously feed, separate, wash and discharge at full speed. It has the characteristics of compact structure, small size, continuous operation, stable operation, strong adaptability, large processing capacity, and low moisture content of filter cake.

LWZ sedimentation concentration type helix

Product structure features: LWZ sedimentation filter decanter centrifuge is a horizontal screw discharge, continuous operation of the filtration equipment. Product use: LWZ sedimentation filter horizontal spiral centrifuge can continuously carry out feeding, concentration, dehydration, washing, discharging and other operations at full speed. Suitable for: suitable for chemical, light industry, pharmaceutical, food, environmental protection and other industries.

GK type horizontal scraper discharges

After the motor drives the drum to run at full speed, the feed valve is automatically opened, and the suspension enters the drum along the feed pipe, in which the liquid phase is centrifugally thrown out through the filter screen and the filter hole of the drum wall, and flows out from the tangential liquid discharge port on the casing, and the solid phase is intercepted in the drum. After reaching the set time, the feeding stops, after a given time of separation and dehydration, the washing valve acts, the washing liquid enters the drum by the washing tube, and the filter cake is washed, and the separation is continued after the washing is over, so that the filter cake reaches the required dryness, and then the material is discharged, and the scraper holder rotates to make the scraper cut into the filter cake layer, scrape the filter cake and exclude it from the hopper.
Application fields: chemical, light industry, food, pharmaceutical and other industries.
Advantages and characteristics: compact structure, small size, continuous operation, stable operation, strong adaptability, large processing capacity, low moisture content of filter cake and so on.

GKH Horizontal (Siphon)

Product structure features: After the motor drives the drum to run at full speed, the feed valve is automatically opened, and the suspension enters the drum along the feed pipe, in which the liquid phase is centrifugally thrown out through the filter screen and the filter hole of the drum wall, and flows out from the tangential discharge port on the casing, and the solid phase is intercepted in the drum. After reaching the set time, the feeding stops, after a given time of separation and dehydration, the washing valve acts, the washing liquid enters the drum by the washing tube, and the filter cake is washed, and the separation is continued after the washing is over, so that the filter cake reaches the required dryness, and then the material is discharged, and the scraper holder rotates to make the scraper cut into the filter cake layer, scrape the filter cake and exclude it from the hopper.

LWL horizontal filter sedimentation centrifuge

LW (LWS) screw pusher centrifuge

LLW type horizontal screw discharge

LWZ sedimentation concentration type helix

GK type horizontal scraper discharges

GKH Horizontal (Siphon)

Plate scraper discharge centrifuge

HG filter sedimentation centrifuge

Suspension plate discharge centrifuge

PS upper discharge centrifuge

PGZ type scraper under discharge centrifugation

HR series two-stage piston pusher

Press 300 type

ABOUT US

Luzhou Jiangyang RedRock Machinery Co., Ltd.

The company is a national high-tech enterprise integrating R & D, production, sales and after-sales service. The company was established in 2009 and has successively joined the Separation Machinery Branch of China General Machinery Industry Association and China Inorganic Salt Industry Association. The company passed the ISO9001-2008 of China Quality Certification Center in 2013 and successfully changed its ISO9001-2015 in 2019.

The company is located in Luzhou National High-tech Zone, close to Luzhou Port, about 10 kilometers away from Yunlong Airport, with a very convenient transportation environment.

One-stop centrifuge professional manufacturer

Hard work, steady work, responsibility

2009
年
公(gōng)司成立
180
+
駕駛員180餘人
80
+
裝(zhuāng)卸人員80餘人
325
+
自有(yǒu)及挂靠車(chē)輛
99
%+
客戶滿意度99%+

Honor

Integrity first, win-win cooperation, do our best to create the greatest value for customers.

Integration of industrialization and industrialization

Contract-abiding and trustworthy enterprise

Rich industry experience

Has joined the China General Machinery Industry Association separation machinery branch, China inorganic salt industry association. With the professional level and mature technology in the field of separation machinery and hydraulic equipment, our company has risen rapidly in the centrifuge industry.

Advanced production equipment

On the basis of fully introducing and absorbing advanced production technology at home and abroad, our company has successfully developed SS series, PGZ series, LW series, LLW series and other centrifuge products, which are widely used in chemical, food, pharmaceutical, environmental protection and other fields. The product quality and excellent technical service have been well received by users.

Complete qualification, quality assurance

The company passed the quality certification of China Quality Certification Center in 2013. The company's strict, refined and humanized management has not only improved the quality of the company's products, but also stabilized a team of high-quality and skilled employees.

COOPERATION CUSTOMERS

In strict accordance with the centrifuge manufacturing standards, the company digests and absorbs advanced technology at home and abroad in product design, compiles detailed and feasible production technology, strictly controls the product quality process, and establishes a perfect sales and after-sales service system. At present, our company has realized the production and sales of plate type, siphon scraper, horizontal screw, bipolar and other series centrifuges, The company's products are widely used in medicine, chemical industry, food, environmental protection and other fields, with first-class product quality, superb technical support and timely and thoughtful service, won the majority of users.
